90Z-2
The JCB 90Z-2 is a powerful zero tailswing compact excavator designed to deliver 9-ton performance in tight and demanding spaces. Built for heavy-duty digging, trenching and lifting, it combines superior breakout force and lifting capability with exceptional control and maneuverability. Powered by a 49 kW(66 hp) JCB by Kohler engine, the 90Z-2 meets Tier 4 Final emissions standards without a DPF, reducing complexity and maintenance. Its durable steel bodywork, fully welded X-frame undercarriage and electro-hydraulic control system make it a reliable and responsive machine for utility work, site development and construction. With a zero tailswing design, the 90Z-2 offers confident operation next to buildings, barriers and trenches without sacrificing performance.Zero tailswing design
Enables confident operation in tight or restricted spaces without overhang
49 kW JCB by Kohler engine
Delivers strong performance with low emissions and no DPF
Electro-hydraulic controls
Provide precise, responsive operation with customizable feel
Heavy-duty construction
Steel panels and reinforced undercarriage for long-term reliability
Specifications
| Operating Weight | Engine | Max Dig Depth | Max Reach at Ground Level | Tailswing | Bucket Breakout Force | Hydraulic Flow | Travel Speed | Cab | Undercarriage |
|---|---|---|---|---|---|---|---|---|---|
| 8,556 kg | 49 kW JCB by Kohler (66 hp) | 4.7 m | 7.52 m | Zero | 58.2 kN | 120 L/min | Up to 5 km/h | Enclosed, pressurized with HVAC and suspension seat | Fully welded X-frame with dozer blade |
